Pollak 52-410 10-Position ATC/ATO Blade Type Fuse Panel - 150 Amp Max, Heavy-Duty Power Distribution

High-Capacity 10-Circuit Power Management for Demanding Fleet Applications

The Pollak 52-410 10-Position Fuse Panel is the ultimate solution for complex electrical rigging in heavy-duty trucks, emergency vehicles, and utility trailers. This high-density panel allows you to centralize up to ten individual DC circuits, providing a clean, organized, and professional power distribution hub for auxiliary lighting, GPS systems, and onboard electronics.

Built to withstand the rigors of the road, the 52-410 is compatible with standard ATC/ATO blade fuses as well as manual or automatic reset blade-style circuit breakers. Its robust construction and high current rating make it a reliable choice for fleet managers and upfitters who require maximum circuit capacity in a compact footprint.

Key Features & Benefits:

• 10-Circuit Expansion: Simplifies complex wiring by managing ten separate circuits from a single input source.

• Maximum Current Handling: Supports a total input of 150 Amps via a heavy-duty #10-32 stud, with each individual circuit rated for up to 30 Amps.

• Superior Connection Stability: Designed with recessed trifurcated fuse contacts to ensure a secure, vibration-resistant grip on fuses and breakers.

• Industrial Durability: Molded from black UL-rated 94V0 thermoplastic, engineered to perform in temperatures ranging from -20°F to 150°F.

• Easy Installation: Features .250" x .032" quick-connect output terminals for fast wiring and recessed mounting holes to prevent accidental electrical shorts.

• Safety Certified: Fully UL recognized and CSA listed for peace of mind in commercial and marine environments.

Technical Specifications:

• Part Number: 52-410 (Bulk) / 52-410P (Retail Pack)

• Number of Positions: 10

• Input Terminal: #10-32 Stud (150A Max Total)

• Output Terminals: .250" x .032" Quick-Connect (30A Max per circuit)

• Material: UL Rated 94V0 Thermoplastic

• Temperature Range: -20°F to 150°F (-29°C to 65°C)

• Dimensions: 2.47" L x 5.05" W x 0.81" H

• Circuit Protection: Accepts ATC/ATO Fuses and Blade-Style Breakers
