Pollak 52-412 12-Position ATC/ATO Blade Type Fuse Panel - 150 Amp Max, Heavy-Duty Power Distribution Hub

Maximum Circuit Expansion for Professional Fleet & Marine Wiring

The Pollak 52-412 12-Position Fuse Panel is the ultimate power distribution solution for complex vehicle electrical systems. Designed for heavy-duty trucks, buses, RVs, and marine vessels, this 12-circuit panel allows you to centralize and protect an extensive array of auxiliary lighting, GPS equipment, communication gear, and safety systems from a single, high-capacity hub.

This rugged panel is built with professional-grade materials and features a versatile design that accepts standard ATC/ATO blade fuses or blade-style, auto/manual reset circuit breakers. Its high current rating and durable thermoplastic construction make it the gold standard for clean, reliable, and safe electrical installations.

Key Features & Benefits:

• 12-Circuit Capacity: The largest in the series, offering maximum scalability for complex wiring projects.

• Heavy-Duty Power Rating: Features a #10-32 stud input rated for a total of 150 Amps max, with output terminals capable of 30 Amps per individual circuit.

• Versatile Protection: Interchangeable terminals accept ATC blade fuses or plug-in style circuit breakers.

• Vibration-Proof Connection: Equipped with recessed trifurcated fuse contacts to ensure maximum electrical grip and consistent conductivity in harsh environments.

• Superior Durability: Molded from black UL-rated 94V0 thermoplastic, engineered to withstand extreme temperatures from -20°F to 150°F.

• Clean & Safe Install: The compact "no top cover needed" design saves space, while recessed mounting holes prevent accidental electrical shorts.

Technical Specifications:

• Part Number: 52-412 (Bulk) / 52-412P (Retail Packaged)

• Number of Positions: 12

• Input Terminal: #10-32 Stud (150A Max Total)

• Output Terminals: .250" x .032" Quick-Connect (30A Max per circuit)

• Material: UL Rated 94V0 Thermoplastic

• Temperature Rating: -20°F to 150°F (-29°C to 65°C)

• Dimensions: 2.47" L x 5.88" W x 0.81" H

• Compliance: UL Recognized and CSA Listed
