Pollak 52-611 Momentary Start Switch – Heavy-Duty Zinc Die-Cast Push-Button (6V-12V)

Industrial-Grade Ignition Control for Harsh Environments

The Pollak 52-611 Momentary Start Switch is a rugged, professional-grade solution designed for automotive, marine, and industrial applications where durability is non-negotiable. Unlike standard switches, the 52-611 features a robust Zinc Die-Cast housing, providing exceptional strength and resistance to the elements.

Built for Heavy-Duty Use

This 2-position switch (Off-On, normally Off) is engineered for long-term reliability in trucks, tractors, and agricultural equipment. Its silver-plated brass terminals ensure maximum electrical conductivity while preventing corrosion, and the heavy-duty mounting bracket ensures a secure fit under high-vibration conditions.

Versatile Installation

The 52-611 is a versatile component that can be used for "push-to-start" applications or as a momentary activation switch for various vehicle circuits. It is suitable for panel mounting or transmission shaft mounting (when used as a single-speed axle switch).

Key Features:

• Housing Material: Heavy-Duty Zinc Die-Cast for maximum durability.

• Action: Momentary Push-Button (Normally Off/Spring Return).

• Dual Voltage Compatible: Designed for 6V and 12V systems.

• Amperage Rating: 25 Amps at 6V; 15 Amps at 12V.

• Corrosion Resistant: Silver-plated brass terminals and a chrome-plated button.

• Secure Connection: Includes (2) #8-32 screw terminals with lock washers.

Specifications:

• Part Number: 52-611 (Bulk) / 52-611P (Packaged)

• Circuitry: SPST, Off-On (Normally Off)

• Mounting Stem: 3/4" Long, 5/8" Diameter (Requires 5/8" hole)

• Cross References: Tectran 19-1041, World American WA06-0021, Cole Hersee 9023
