Pollak 54-530PL 30 Amp Type 1 Automatic Reset Circuit Breaker – Plastic Housing with Straight Bracket

Provide maximum electrical protection in the harshest environments with the Pollak 54-530PL 30 Amp Circuit Breaker. This high-capacity, Type 1 "Automatic Reset" breaker is specifically designed for heavy-duty 12V DC systems that require both serious amperage and total resistance to corrosion. Equipped with a pre-installed straight mounting bracket, the 54-530PL allows for a clean, flush-mount installation on firewalls, chassis rails, or exterior panels.

The 54-530PL features a high-impact, non-conductive plastic housing that is 100% rust-proof. This design is a critical upgrade for salt-spreader trucks, marine vessels, and agricultural equipment where chemical sprays and road salt are common. As a Type 1 breaker, it ensures maximum vehicle uptime by automatically cycling and resetting once an electrical fault or overload is cleared. This makes it the ideal primary protection for 30 Amp auxiliary loads like power tarp systems, lift gate controls, and high-output lighting arrays.

Key Features:

• Integrated Straight Bracket: Designed for easy, flush-mount installation on flat surfaces for a secure, low-profile fit.

• Corrosion-Proof Plastic Body: High-impact, non-conductive housing provides a permanent solution to rust and environmental wear.

• Type 1 Auto-Reset: Automatically restores power once the fault is corrected, ensuring continuous operation without manual intervention.

• 30 Amp High-Capacity Protection: Engineered to handle mid-to-high draw 12V DC auxiliary systems and equipment.

• Vibration-Resistant Terminals: Features (2) #10-32 threaded studs for a secure, high-torque connection with heavy-gauge ring terminals.

Technical Specifications:

• Part Number: 54-530PL

• Amperage: 30 Amp

• Voltage: 12V DC

• Reset Type: Type 1 (Automatic)

• Mounting Style: Straight (Flush-Mount) Bracket

• Housing Material: High-Impact Plastic (Corrosion-Resistant)
