Pollak 54-630PL 30 Amp Type III Manual Reset Circuit Breaker – Corrosion-Resistant Plastic Housing

Take control of your vehicle's electrical safety with the Pollak 54-630PL 30 Amp Circuit Breaker. This Type III "Manual Reset" breaker is a high-performance safety component designed to protect 12V DC circuits from overloads and shorts. Unlike automatic breakers that cycle power, the 54-630PL trips and stays "off" until the user manually resets the lever. This feature is essential for protecting motors and sensitive equipment from the heat damage caused by continuous cycling.

The 54-630PL is built with a high-impact, non-conductive plastic housing, providing 100% rust protection. It is the ideal upgrade for salt-spreader trucks, marine applications, and agricultural equipment where standard metal breakers often fail due to corrosion. With a 30 Amp rating, it is perfectly suited for protecting auxiliary power leads, lift gates, power tarp systems, and heavy-duty lighting controllers.

Key Features:

• Type III Manual Reset: The breaker remains tripped until manually reset, allowing for safe fault identification and preventing equipment damage.

• Corrosion-Proof Plastic Body: Non-conductive and rust-resistant housing designed for high-moisture and salty environments.

• 30 Amp High-Capacity Protection: Engineered for mid-to-high draw 12V DC auxiliary systems and specialized motors.

• Visible Trip Indicator: The reset lever provides an immediate visual signal that the breaker has tripped, simplifying troubleshooting.

• Standard Stud Terminals: Features (2) #10-32 threaded studs for a secure, vibration-resistant connection with ring terminals.

Technical Specifications:

• Part Number: 54-630PL

• Amperage: 30 Amp

• Voltage: 12V DC

• Reset Type: Type III (Manual Reset)

• Housing Material: High-Impact Plastic

• Terminal Type: Dual Threaded Studs
