Pollak 54-861PL 100 Amp Type I Automatic Reset Circuit Breaker – Plastic Housing

Reliable Overcurrent Protection for Heavy-Duty Electrical Systems

Protect your vehicle’s vital electrical circuits with the Pollak 54-861PL 100 Amp Circuit Breaker. Engineered for high-performance environments, this Type I (Automatic Reset) breaker is the industry standard for auxiliary and accessory circuits in trucks, buses, RVs, and marine applications.

Built to Withstand Harsh Environments

Featuring a rugged thermoset plastic housing (UL rated 94V0), the Pollak 54-861PL is designed to resist extreme temperatures, vibration, and impact. Its sealed construction makes it splash-proof and dust-proof, ensuring reliable operation even when mounted in engine compartments or bilge areas.

Key Features & Benefits:

• Automatic Reset (Type I): Automatically resets after tripping once the overload is cleared, minimizing downtime and eliminating the need for manual intervention.

• High Amperage Capacity: Rated for 100 Amps DC at 30VDC, ideal for winches, battery chargers, and DC audio systems.

• Durable Plastic Housing: Non-corrosive thermoset plastic provides superior insulation and longevity compared to metal alternatives.

• Easy Installation: Features a panel-mount design with two-stud terminals for secure, bolt-on connectivity.

• Safety Standards: Complies with SAE J1625 standards for ignition protection and performance.

Technical Specifications:

• Part Number: 54-861PL

• Amperage: 100 Amp

• Voltage: 30 VDC

• Reset Type: Type I (Auto Reset)

• Housing: Thermoset Plastic (UL 94V0)

• Operating Temp: -25°F to 180°F (-32°C to 82°C)

• Terminals: 2 Studs (Bolt-on)

• Ingress Protection: Splash-proof and Dust-proof
