Pollak 54-863PL 80 Amp Type I Automatic Reset Circuit Breaker – High-Amp Plastic Housing

Heavy-Duty Electrical Protection for Demanding Environments

The Pollak 54-863PL 80 Amp Circuit Breaker is a professional-grade thermal breaker designed to provide superior overcurrent protection for auxiliary and accessory circuits. Whether you are outfitting a heavy-duty truck, bus, RV, or marine vessel, this Type I automatic reset breaker ensures your electrical system remains safe and operational without the need for manual fuse replacements.

Resilient Design & Engineering

Built with a rugged thermoset plastic housing (UL rated 94V0), the Pollak 54-863PL is engineered to withstand extreme under-hood temperatures and harsh environments. Its sealed, splash-proof, and dust-proof construction makes it the ideal choice for engine compartments and bilge areas where moisture and debris are constant threats.

Key Features & Benefits:

• Automatic Reset (Type I): Continuously cycles during an overcurrent condition and automatically resets once the fault is cleared, reducing equipment downtime.

• 80 Amp Capacity: High-amperage rating perfect for battery chargers, DC audio systems, winches, and auxiliary lighting.

• SAE J1625 Compliant: Meets industry-standard safety and performance requirements for ignition protection.

• Thermoset Plastic Housing: Durable, non-corrosive material that resists heat and chemical exposure.

• Easy Installation: Designed for panel or surface mounting with secure two-stud terminal connections.

Technical Specifications:

• Part Number: 54-863PL (Package version: 54-863PLP)

• Amperage: 80 Amps DC

• Voltage: 30 VDC

• Reset Type: Type I (Auto Reset)

• Housing Material: Thermoset Plastic (UL Rated 94V0)

• Operating Temperature: -25°F to 180°F (-32°C to 82°C)

• Storage Temperature: -30°F to 300°F (-34°C to 149°C)

• Mounting: Panel or Surface Mount

• Terminals: 2 Studs
