Pollak 54-870PL 60 Amp Type III Manual Reset Circuit Breaker – Waterproof Plastic Housing

Enhanced Safety and Control for Heavy-Duty Electrical Circuits
The Pollak 54-870PL 60 Amp Circuit Breaker provides premium overcurrent protection with the added safety of a Type III Manual Reset mechanism. Unlike automatic breakers, the Type III design remains tripped until manually reset, allowing operators to identify and fix electrical faults before restoring power—an essential feature for high-value auxiliary equipment in trucks, RVs, and marine vessels.

Built for the Elements
Constructed with a high-grade thermoset plastic housing (UL 94V0), this breaker is built to perform in the harshest environments. It is completely sealed to be splash-proof and dust-proof, making it ideal for engine bays, chassis mounting, or marine bilge applications where exposure to moisture and vibration is common.

Key Features & Benefits:

• Manual Reset (Type III): Provides a visible trip indicator and remains "off" until the manual lever is reset, ensuring maximum safety during troubleshooting.

• 60 Amp Performance: Optimized for mid-to-high range power demands such as lift gates, auxiliary lighting, small winches, and trolling motors.

• Ignition Protected: Complies with SAE J1625 standards, making it safe for use in gasoline-powered engine compartments and marine environments.

• Durable Thermoset Plastic: Non-corrosive, heat-resistant housing ensures long-term durability compared to standard metal-case breakers.

• Secure Connection: Dual-stud terminal design ensures a vibration-resistant, bolt-on connection for heavy-gauge wiring.

Technical Specifications:

• Part Number: 54-870PL

• Amperage: 60 Amps

• Voltage: 30 VDC

• Reset Type: Type III (Manual Reset)

• Housing Material: Thermoset Plastic (UL Rated 94V0)

• Operating Temperature: -25°F to 180°F (-32°C to 82°C)

• Compliances: SAE J1625, SAE J1171 (Ignition Protected)

• Terminals: 2 Studs (1/4")
