Pollak 54-871PL 100 Amp Type III Manual Reset Circuit Breaker – High-Amp Plastic Housing

The Ultimate Protection for High-Current Auxiliary Circuits
The Pollak 54-871PL 100 Amp Circuit Breaker is engineered for heavy-duty applications that demand both high power and maximum safety. As a Type III Manual Reset breaker, it provides a definitive "trip" during an overcurrent event, remaining disconnected until a technician or operator manually resets the lever. This prevents the dangerous "cycling" effect of automatic breakers in high-amperage short-circuit scenarios.

Rugged Construction for Commercial Use
Designed to survive the rigors of the road and the sea, the 54-871PL features a non-corrosive, thermoset plastic housing. It is built to operate in high-temperature engine compartments and is sealed against dust and moisture, making it a "fit and forget" solution for critical power paths.

Key Features & Benefits:

• Manual Reset Safety (Type III): Features a visible reset lever that acts as a trip indicator, ensuring the circuit stays dead until it is safe to re-energize.

• 100 Amp Rating: Perfect for high-draw equipment including large winches, hydraulic lift gates, heavy-duty battery chargers, and high-output DC power converters.

• Weatherproof Design: Sealed housing is splash and dust-proof, ideal for chassis-mount or marine bilge environments.

• Ignition Protected: Complies with SAE J1625 and J1171 standards, allowing for safe installation in gas-engine compartments.

• Superior Insulation: The thermoset plastic body (UL 94V0) provides better thermal and electrical insulation than standard metal breakers.

Technical Specifications:

• Part Number: 54-871PL

• Amperage: 100 Amps

• Voltage: 30 VDC

• Reset Type: Type III (Manual Reset)

• Housing: Thermoset Plastic (UL Rated 94V0)

• Operating Temperature: -25°F to 180°F (-32°C to 82°C)

• Compliance: SAE J1625, SAE J1171 (Ignition Protected)

• Terminals: 2 Studs (1/4" Bolt-on)
