Pollak 54-875PL 200 Amp Type III Manual Reset Circuit Breaker – Surface Mount, Waterproof Plastic Housing

Extreme Power Protection for High-Draw DC Systems
When your equipment demands maximum power, the Pollak 54-875PL delivers the protection you need. This 200 Amp Type III Thermal Circuit Breaker is the heavy-duty solution for safeguarding high-amperage auxiliary circuits. Whether you are powering massive winches, hydraulic lift gates, or large-scale marine electronics, this breaker ensures your electrical system remains safe from catastrophic overloads.

Manual Reset & Emergency Shut-Off
The 54-875PL isn't just a breaker; it’s a control center. Featuring a high-visibility manual reset lever, it provides an instant visual confirmation if a circuit trips. As a "Type III" switchable breaker, it also allows you to manually trip the connection, acting as a dedicated shut-off switch for maintenance or to prevent battery drain during long-term storage.

Engineered for the Long Haul
Built to thrive where others fail, this breaker features a rugged, non-corrosive thermoset plastic housing (UL rated 94V0). It is sealed, splash-proof, and dust-proof, and carries an ignition protected rating. This makes it the ideal choice for engine compartments, battery banks, and bilge areas where exposure to heat, moisture, and vibration is guaranteed.

Key Features:

• 200 Amp Rating: Engineered for the highest demand DC applications.

• Type III Manual Reset: Features a visible trip indicator and manual "off" switch capability.

• Surface Mount Design: Integrated mounting flange for a secure, low-profile installation.

• All-Weather Durability: Fully sealed housing protects against water, salt, and debris.

• Safety Certified: Meets SAE J1625 standards for heavy-duty circuit protection.

Common Applications:

• Heavy-duty truck lift gates and snow plows

• Industrial winches and cranes

• Marine primary power distribution

• Large RV power inverters and battery banks

Technical Specifications

• Part Number: 54-875PL (Interchangeable with 54-875PLP)

• Amperage: 200 DC Amps

• Voltage: 30 VDC Max

• Reset Type: Type III – Manual Reset (Switchable)

• Housing: Thermoset Plastic (UL rated 94V0)

• Mounting: Surface Mount

• Operating Temperature: -25°F to 180°F (-32°C to 82°C)

• Terminals: 1/4-28 threaded studs with protective insulators

• Standards: SAE J1625 / Ignition Protected
