Pollak 54-876PL 250 Amp Type III Manual Reset Circuit Breaker – Surface Mount, Waterproof Plastic

Ultimate Protection for Maximum Amperage Loads
The Pollak 54-876PL is a robust 250 Amp Type III Thermal Circuit Breaker, designed to safeguard the most demanding electrical circuits in your vehicle or vessel. As the highest amperage model in the Pollak plastic housing series, it is the go-to choice for protecting primary power feeds, massive inverter banks, and high-capacity hydraulic systems found in the trucking and marine industries.

Manual Control & High Visibility
Safety is critical when handling 250 Amps. The 54-876PL features a high-visibility manual reset lever that pops out to show a tripped condition instantly. Because it is a "Type III" switchable breaker, it also provides the functionality of a manual kill switch, allowing you to isolate the circuit during maintenance or when the vehicle is in long-term storage to prevent parasitic battery drain.

Extreme Durability for Harsh Environments
Engineered for the "hot zones" of trucks and boats, this breaker is housed in a thermoset plastic (UL rated 94V0) that resists corrosion and high temperatures. It is fully sealed, splash-proof, and dust-proof, ensuring reliable operation even when exposed to road spray or engine bay debris. It is also ignition protected, making it safe for use in gasoline engine compartments.

Key Features:

• 250 Amp Rating: Built for the heaviest DC electrical loads.

• Manual Reset (Type III): Visible trip indicator with manual "off" switching capability.

• Sealed Housing: Waterproof and dust-proof construction for external or engine bay mounting.

• Compact Surface Mount: Features integrated mounting holes for a secure, flat-surface installation.

• Compliance: Meets SAE J1625 standards for heavy-duty ignition protection.

Common Applications:

• Heavy-duty winches and recovery equipment

• Large RV power inverters and solar arrays

• Marine primary power and bow thrusters

• Commercial truck lift gates and hydraulic pumps

Technical Specifications

• Part Number: 54-876PL (Interchangeable with 54-876PLP)

• Current Rating: 250 Amps

• Voltage Rating: 30 VDC Max

• Reset Type: Type III – Manual Reset (Switchable)

• Mounting: Surface Mount

• Housing: Thermoset Plastic (UL rated 94V0)

• Operating Temperature: -25°F to 180°F (-32°C to 82°C)

• Terminals: 1/4-28 threaded studs with protective insulators

• Certifications: SAE J1625 / Ignition Protected
