Pollak 54-882PL 150 Amp Type III Manual Reset Circuit Breaker – Surface Mount, Waterproof Plastic

Heavy-Duty Circuit Protection for High-Demand Systems
The Pollak 54-882PL is a professional-grade 150 Amp Type III Thermal Circuit Breaker, engineered to handle the high-amperage demands of modern commercial vehicles and marine vessels. This breaker is the ideal safeguard for auxiliary power circuits, large inverter setups, and heavy-duty hydraulic equipment, ensuring your electrical system remains protected against dangerous overcurrent conditions.

Manual Reset Control & Visual Safety
The 54-882PL is designed with an intuitive manual reset lever that provides an immediate, clear visual indicator if the circuit has tripped. As a "Type III" switchable breaker, it also functions as a manual disconnect. This allows you to intentionally trip the breaker to the "Off" position, providing a convenient way to isolate the circuit for maintenance or to prevent battery drain during long-term storage.

Sealed for Survival in Harsh Environments
Engineered to thrive where standard breakers fail, the 54-882PL features a rugged thermoset plastic housing (UL rated 94V0) that resists corrosion, high heat, and heavy vibration. The unit is fully sealed, splash-proof, and dust-proof, making it perfect for installation in engine compartments, near battery banks, or in marine bilge areas. It is also ignition protected, meeting the highest safety standards for gas-powered environments.

Key Features:

• 150 Amp Rating: Reliable protection for high-draw DC power accessories.

• Type III Manual Reset: High-visibility trip lever with manual "off" switching capability.

• Rugged Construction: Sealed plastic housing resists corrosion, moisture, and road debris.

• Surface Mount Design: Integrated mounting flange for a secure, low-profile installation.

• Safety Certified: Complies with SAE J1625 standards for heavy-duty circuit protection.

Common Applications:

• Commercial truck lift gates and snow plow motors

• Marine primary power and large trolling motors

• RV power inverters and solar charging arrays

• Emergency vehicle equipment and high-output lighting

Technical Specifications

• Part Number: 54-882PL (Interchangeable with 54-882PLP)

• Current Rating: 150 DC Amps

• Voltage Rating: 30 VDC Max

• Reset Type: Type III – Manual Reset (Switchable)

• Housing Material: Thermoset Plastic (UL 94V0)

• Mounting Type: Surface Mount

• Operating Temperature: -25°F to 180°F (-32°C to 82°C)

• Hardware: 1/4-28 threaded studs (includes protective insulators)

• Certifications: SAE J1625 / Ignition Protected
