Pollak 54-883PL 80 Amp Type III Manual Reset Circuit Breaker – High-Amp Plastic Housing

Protect your vehicle’s electrical system with the Pollak 54-883PL, a heavy-duty 80 Amp Type III thermal circuit breaker. Designed for high-performance reliability, this manual reset breaker provides a visible indication of a tripped condition, ensuring you can quickly identify and resolve electrical overloads. Built with a rugged thermoset plastic housing, it is specifically engineered to withstand the vibrations and harsh environments common in trucking, marine, and RV applications.

Key Features:

• Manual Reset Safety: As a Type III breaker, the 54-883PL remains open after a trip until manually reset. The unique reset mechanism offers a clear visual cue when the circuit has been interrupted.

• Built for Durability: The one-piece thermoset plastic housing is lighter than traditional metal versions and eliminates the risk of terminal shorting against the case. It is also splash-proof and dust-proof, making it ideal for engine compartments and bilge areas.

• Precision Engineering: Complies with SAE Standard J1625 for high-amp circuit protectors. It features high-grade internal components for consistent functional operation under heavy loads.

• Versatile Mounting: Designed for panel or surface mounting, providing flexible installation options for auxiliary and accessory circuits.

Typical Applications:

• Heavy-duty trucks and buses

• Marine bilge and electrical systems

• RV and camper accessory circuits

• Battery chargers and high-power DC audio systems

Technical Specifications:

• Amperage: 80 Amp

• Voltage: 30 VDC

• Reset Type: Type III (Manual Reset)

• Housing: Thermoset Plastic (UL Rated 94V0)

• Operating Temp: -25°F to 180°F (-32°C to 82°C)

• Standards: SAE J1625

• Terminals: Two stud terminals for secure connections
