Pollak 54-920PL Sealed 20 Amp Circuit Breaker – Type I Automatic Reset with 12-Inch Wire Loop

Reliable Circuit Protection for Demanding Environments
Ensure your vehicle’s electrical system is protected against overloads and short circuits with the Pollak 54-920PL 20 Amp Sealed Circuit Breaker. Specifically designed for heavy-duty applications in trucks, RVs, and trailers, this Type I automatic reset breaker provides continuous protection without the need for manual intervention.

Built for the Elements
The 54-920PL is engineered for exposed applications where moisture, dust, and oil are a constant threat. Its sealed housing ensures longevity and reliability, making it the go-to choice for under-hood or exterior mounting. Unlike standard breakers, this model comes equipped with a 12-inch wire loop, providing maximum flexibility for custom wiring and easy installation in tight spaces.

Key Features & Benefits:

• Automatic Reset (Type I): Cycles continuously during an over-current condition and automatically resets once the fault is cleared.

• Sealed Design: Perfect for exposed environments; resistant to oil, humidity, and road grime.

• Integrated 12" Wire Loop: Simplifies installation by allowing you to cut and strip the lead to your exact requirements.

• Heavy-Duty Performance: 20 Amp rating at 12V DC, compliant with SAE Standard J553 for automotive circuit breakers.

• Versatile Application: Ideal for brake controllers, battery chargers, accessory lighting, and more on commercial trucks, buses, and RVs.

Technical Specifications

• Brand: Pollak (Stoneridge)

• Part Number: 54-920PL (also referenced as 54-920)

• Amperage: 20 Amps

• Voltage: 12V DC

• Reset Type: Type I Automatic Reset

• Wire Lead: 12-inch loop

• Housing: Sealed for moisture and dust resistance

• Compliance: SAE J553
