Pollak 54-940 Sealed 40 Amp Circuit Breaker – Type I Automatic Reset with 12-Inch Wire Loop

Reliable Overcurrent Protection for Rugged Environments
The Pollak 54-940 is a high-performance, Type I sealed circuit breaker designed to provide dependable protection for heavy-duty electrical systems. Engineered for 12VDC applications, this 40 Amp breaker is built to withstand the harshest conditions, making it an essential component for trucks, RVs, buses, and marine equipment.

Sealed Design for Maximum Durability
Unlike standard breakers, the 54-940 features a sealed housing specifically designed for exposed applications. Whether your vehicle is facing moisture, dust, road salt, or oil, this unit remains protected, ensuring consistent performance and preventing premature electrical failure.

Effortless Integration with 12-Inch Wire Loop
Installation is streamlined with the included 12-inch wire loop, allowing for flexible mounting and easy connection to your existing wiring harness. This Type I breaker utilizes a cycling automatic reset mechanism—it continuously cycles during an overcurrent condition and automatically returns to run mode once the fault is cleared, eliminating the need for manual resets in hard-to-reach areas.

Key Features & Benefits:

• Automatic Reset (Type I): Continuous cycling protects your circuits without permanent shutdown.

• 40 Amp Rating: Ideal for headlamps, tail lamps, battery chargers, cooling fans, and trolling motors.

• Environmentally Sealed: Built to resist moisture, dust, and oil in exposed chassis or engine bay locations.

• SAE J553 Compliant: Meets rigorous industry standards for safety and reliability.

• Temperature Resistant: Operates efficiently in extreme climates ranging from -10°F to 150°F.

Technical Specifications:

• Part Number: 54-940 (Package No. 54-940P)

• Current Rating: 40 DC Amps

• Voltage: 12 VDC

• Reset Type: Type I Cycling Automatic

• Lead Length: 12-inch wire loop

• Standards: Complies with SAE J553
