Pollak 54-960 Mini-Style 30 Amp Circuit Breaker – Type II Modified Reset (Paccar HD 8)

High-Amperage Protection for Paccar, Kenworth, and Peterbilt Systems
The Pollak 54-960 is a heavy-duty 30 Amp circuit breaker designed in the ultra-compact Mini-blade (ATM) footprint. Specifically engineered to meet the rigorous electrical demands of Paccar HD 8 series vehicles, this breaker is the professional's choice for replacing standard 30A mini-fuses with a high-performance, resettable solution.

Type II Modified Reset: Safety for High-Draw Circuits
Managing 30 Amps in a mini-style format requires precision safety. The 54-960 utilizes Type II Modified Reset technology. Unlike standard cycling breakers, this unit trips and remains open as long as power is applied to the circuit. It will only reset once the ignition is turned off or the power source is disconnected. This non-cycling behavior prevents the dangerous "on-off" loop that can lead to heat buildup, protecting your Paccar vehicle’s wiring harness and sensitive electronics from cumulative damage.

Engineered for the Long Haul
Built to handle the high-vibration environment of vocational and over-the-road trucks, the 54-960 features a rugged construction that far outlasts traditional fuses. It provides a permanent, resettable solution for high-draw circuits, significantly reducing downtime and the need for spare fuse inventory.

Key Features & Benefits:

• Type II Modified Reset: Safety-first design stays tripped until power is cut—prevents continuous cycling and protects wiring.

• Paccar HD 8 Optimized: Specifically tailored for Paccar/Peterbilt/Kenworth heavy-duty truck electrical specs.

• Mini-Style (ATM) Format: Direct-fit replacement for standard 30 Amp Mini blade fuses.

• 30 Amp Capacity: Ideal for heavy-load circuits such as blower motors, power seats, and auxiliary power outlets.

• SAE J553 Compliant: Engineered to meet the highest industry safety and performance standards.

• Compact Durability: Provides high-amperage protection in a footprint designed for dense power distribution modules.

Technical Specifications:

• Part Number: 54-960 (Package No. 54-960P)

• Current Rating: 30 Amps

• Voltage: 12VDC

• Reset Type: Type II (Modified Reset / Non-Cycling)

• Style: Mini-Blade Plug-In (ATM Style)

• Application: Paccar HD 8 Series (Kenworth/Peterbilt)
