Dual-Contact Multi-Functionality: Safely operates as both an auxiliary/side turn signal and a rear marker/clearance light, condensing hardware needs into a single unit.
-
Rear-Vehicle Optimization: Specially engineered with a vibrant red lens, making it compliant for rear-positioned vehicle signaling and side-marker applications.
-
Protective Mounting Gasket Included: Comes with a heavy-duty gasket that creates a tight, weather-resistant seal against the vehicle body while dampening road shock and vibration.
-
Permanently Sealed Housing: The robust polycarbonate lens and housing are sonic-welded together to deliver a moisture-proof and dustproof barrier that extends bulb life.
-
Complete Installation Kit: Packaged with the sealed lamp, a protective gasket, and a 3-wire right-angle PL-3 pigtail harness featuring a stripped-end/ring terminal finish for fast fleet retrofitting.
SKU
22004R
Manufactures SKU
TRUCK-LITE 22004R
Truck-Lite 22004R 22 Series Red Rectangular Incandescent Side Turn Signal Kit with Gasket, 12V
$19.09
EA
Ensure heavy-duty rear-vehicle signaling compliance with the Truck-Lite 22004R 22 Series Red Rectangular Side Turn Signal Kit. This versatile, dual-contact 2" x 6" lamp assembly acts as both a side/auxiliary turn signal and a rear marker/clearance light within a single unit. Engineered to endure harsh over-the-road environments, it features a rugged, impact-resistant polycarbonate lens and housing that are permanently sealed against dirt and moisture. This complete install-ready kit comes outfitted with a heavy-duty mounting gasket to cushion vibrations, alongside a right-angle PL-3 plug terminating in stripped wires and a ring terminal for a secure, professional electrical hookup.
Features & Benefits
Brand
TRUCK-LITE
Common Size
2 x 6
Current Major Amp
2.1
Current Minor Amp
0.49
Housing Material
Polycarbonate
KIT
Yes
Lamp Connection
PL-3
Lens Color
Red
Lens Height
2.4
Lens Material
Polycarbonate
Lens Shape
Rectangular
Lens Width
5.94
Lighting Technology
Incandescent
Mount Type
2 Screw
Number of Diodes/Bulbs
1
Number of Wires
3
Position
Side
Product Type
Turn Signal
Sealed/Bulb Replaceable
Sealed
Series
22 Series
Voltage
12
Wire Gauge
16
Compliance Family
FMVSS 108 | CMVSS 108 | DOT | SAE
Standards Met
P2 | E
UPC
0735111040224
UNSPSC
25172900
VMRS
034-003-081
Warranty
1-Year
Shipping Weight (lbs)
0.400000
Total Height
2.4
Total Width
5.94
