Truck-Lite 262 Signal-Stat 10-Light Electro-Mechanical Flasher – 2-Blade, 12V

The Truck-Lite 262 Signal-Stat Flasher Module is a high-performance, electro-mechanical solution designed for heavy-duty signaling applications. Capable of powering up to 10 lamps simultaneously, this flasher is ideal for commercial trucks, trailers, and utility vehicles that require consistent, DOT-compliant turn signal and hazard performance.

Built with a double coil relay and advanced electronic components, the Signal-Stat 262 ensures a quick response time—flashing within 1.5 seconds of activation. Its bi-polar design allows for versatile installation, making it a reliable workhorse for any 12V electrical system.

Key Features & Benefits:

• High Lamp Capacity: Supports up to 10 lamps (20 Amp max), providing enough power for complex trailer lighting setups.

• Superior Reliability: Features a double coil relay design for enhanced durability and a service life that outlasts standard flashers.

• Quick Response: Flashes at a consistent rate of 60 to 120 FPM, with the first flash occurring in less than 1.5 seconds for immediate signaling.

• Bi-Polar Functionality: Operates continuously at 13V for up to 36 hours, offering flexibility in wiring and ground configurations.

• Rugged Housing: Encased in a black polycarbonate plastic shell to resist impact and environmental wear.

• Easy Plug-and-Play: Uses standard 1/4" male blade terminals for a secure, hassle-free connection to existing ISO or custom bases.

Technical Specifications:

• Brand: Truck-Lite / Signal-Stat

• Part Number: 262

• Voltage: 12V

• Current Rating: 20 Amp Max

• Lamp Capacity: 10 Lamps

• Connection Type: 2-Blade (1/4" Male Terminals)

• Flash Rate: 60 - 120 Flashes Per Minute (FPM)

• Mechanism: Electro-Mechanical

• Housing: Black Plastic

• Standards Met: FMVSS 108, SAE J590, SAE J945, DOT Approved

• VMRS Code: 034-006-029

• Dimensions: 1.37" (H) x 1.37" (W) x 1.77" (D)
