High Capacity: Supports up to 10 lights (20 Amp max) with 10-32 CP lamps.
-
Rapid Response: Features a quick-start design with the first flash in under 1.5 seconds.
-
Universal Connection: Uses standard 1/4" male blade terminals for easy "plug-and-play" installation.
-
Standards Compliant: Meets or exceeds FMVSS 108, DOT, and SAE (J590, J945) safety standards.
-
Rugged Construction: Durable black plastic housing designed to withstand harsh road conditions.
-
Versatile Replacement: Direct replacement for Truck-Lite 97202, 97203, and 97204 series modules.
SKU
263
Manufactures SKU
TRUCK-LITE 263
Truck-Lite 263 Signal-Stat Electro-Mechanical 10-Light Flasher Module – 12V, 3-Blade Terminal
$18.05
EA
Reliable Signaling Performance for Heavy-Duty Applications
The Truck-Lite 263 Signal-Stat Flasher Module is a high-performance electro-mechanical solution designed for 12V vehicle lighting systems. Built to handle up to 10 lights, this heavy-duty flasher ensures consistent, high-visibility signaling for trucks, trailers, and commercial vehicles.
Advanced Engineering & Durability
Featuring a double-coil relay and integrated electronic components, the 263-model provides superior timing accuracy and long-term reliability. Its bi-polar design is engineered for endurance, capable of functioning continuously at 13V for up to 36 hours. With a flash rate of 60 to 120 FPM (Flashes Per Minute), it provides a rapid response with the first flash occurring in less than 1.5 seconds after startup.
Features & Benefits
Audible
No
Brand
Signal-Stat
Current Amp
20
Flasher Mechanism
Electro-Mechanical
Housing Material
Plastic
KIT
No
Lamp Connection
3 Blade Terminals
Mount/Trim Color
Black
Mount/Trim Material
Plastic
Number of Lamps
10
Product Type
Flasher Module
Series
Signal-Stat
Strobe Frequency Max
120
Strobe Frequency Min
60
Voltage
12
Compliance Family
FMVSS 108 | DOT | SAE
Standards Met
J590 | J945
UPC
0724956083503
UNSPSC
39000000
VMRS
034-006-029
Warranty
1-Year
Shipping Weight (lbs)
0.120000
Total Height
1.37
Total Width
1.37
Replaces Truck-Lite 97203
Grote 44820 replacement
Velvac 091216 equivalent
NAPA 263 flasher
