SKU
4855
Manufactures SKU
TRUCK-LITE 4855
Signal-Stat - Incandescent - Red/Yellow Square - 3 Bulb - LH - Single Face - Horizontal Mount - Side Marker - Pedestal Light - Bracket Mount - Black
Special Price
$54.85
Regular Price
$59.79
Signal-Stat - Single Face - LH - Horizontal Mount - Incan. - Red/Yellow Square - 3 Bulb - Black - Pedestal Light
**Discontinued - Available While Supply Lasts
Features & Benefits
Replaces GM #694627 (LH) and #694628 (RH) - Combination park - turn - side marker and reflex reflector - Mounting hardware included - Mounts on 320" centers and connects with 2 spade terminals - Unique GM harness connector (harness not available from Truck-Lite)
Brand
Signal-Stat
Common Size
4.5 x 4.5
Current Major Amp
2.1
Current Minor Amp
0.5
Housing Color
Black
Housing Material
ABS
KIT
No
Lamp Connection
Spade Terminal
Lens Color
Red | Yellow
Lens Height
4.32
Lens Material
Acrylic
Lens Shape
Square
Lens Width
4.62
Lighting Technology
Incandescent
Mount Type
Bracket Mount Kit
Mounting Connector Diameter
0.286
Mounting Orientation
Horizontal
Number of Diodes/Bulbs
3
Number of Faces
Single Face
Position
Left Hand Side
Product Type
Pedestal Light
Sealed/Bulb Replaceable
Bulb Replaceable
Series
Signal-Stat
Voltage
12
Compliance Family
FMVSS 108 | DOT | SAE
Standards Met
I6 | A
UPC
0724956144501
UNSPSC
25172900
VMRS
034-003-071
Warranty
1-Year
Shipping Weight (lbs)
0.400000
Total Height
4.32
Total Width
4.63
