Extended Perimeter Illumination: Projects daylight-like LED illumination up to 5 feet around the vehicle perimeter for increased job-site safety and ground visibility.
-
12° Angled Optics & Low Profile: Angled design directs light downward and outward while maintaining a sleek profile that protrudes only 2.5 inches from the surface.
-
Heavy-Duty Construction: Heavy-duty die-cast aluminum housing with heat-dissipating rear fins to protect LED circuitry and maximize longevity.
-
Energy-Efficient LED Output: 6 high-output white LEDs produce high light intensity at a low power draw (1.2A at 12V DC).
-
Corrosion-Resistant Wiring: Hardwired 2-wire lead with .180 bullet terminals prevents terminal pin corrosion and eliminates the need for extra adapter harnesses.
-
Weather & Impact Resistant: Sealed, clear polycarbonate lens defends against harsh weather, road debris, and heavy vibration.
Truck-Lite 81335C – 81 Series 3" x 9" Rectangular LED Perimeter Light (6 Diode, Clear Lens, 12V, Surface Mount, .180 Bullet Terminals)
Expand your vehicle’s workspace lighting with the high-performance Truck-Lite 81335C 81 Series 3x9 Rectangular LED Perimeter Light. Specially engineered to illuminate critical ground and surround zones, this low-profile perimeter light projects up to 5 feet of supplemental light around the vehicle—reaching areas standard dome or back-up lights miss.
Built for heavy-duty commercial applications, the Truck-Lite 81335C features a rugged die-cast aluminum housing coated in a durable gray finish, paired with an impact-resistant clear polycarbonate lens. Its smart design incorporates a 12° light angle to throw illumination far beyond the housing, while integrated rear cooling fins draw heat away from the 6 high-output LEDs to ensure long diode life and maximum output (up to 1,000 lumens).
Operating efficiently on 12V DC with minimal electrical draw (1.2A), multiple units can be installed on a single circuit without overloading your electrical system. Equipped with a surface mount configuration and hardwired 2-wire leads with corrosion-resistant .180 bullet terminals, the Truck-Lite 81335C installs easily on liftgate trailers, utility bodies, work trucks, and commercial fleets available at TruckLightParts.com.
Ideal Applications
-
Commercial Truck Bodies & Service Vans
-
Liftgate Trailers & Flatbeds
-
Towing, Utility, & Construction Vehicles
-
Emergency & Work-Site Support Fleet Vehicles
(Note: Care should be taken to install this device so that it does not operate while the vehicle is in motion on public roadways.)
