Application Profile: Universal wide-angle side-view blind spot monitoring accent mirror
-
Common Industry Size: 5-Inch (5" Diameter Profile)
-
Lens Glass Style: High-Visibility Curved Convex Lens (Panoramic Wide-Angle Vision)
-
Mirror Shape: Round
-
Housing Material: Heavy-Gauge Machined Stainless Steel
-
Housing Color / Finish: Metallic Silver / High-Polish
-
Mounting Connector Type: 5/16" Adjustable Female Threaded Ball Stud & Mount (0.313" Connection Diameter)
-
Included Mounting Hardware: Heavy-Duty Zinc-Plated Universal Structural Steel "L" Bracket Pack
-
Total Product Dimensions: 5.00" Total Height x 5.00" Total Width x 1.75" Total Depth (127mm H x 127mm W x 44.45mm D)
Truck-Lite 97618 5-Inch Round Stainless Steel Convex Blind Spot Mirror (High-Polish Silver Housing, Universal 5/16" Ball Stud Mount with L-Bracket)
Eliminate dangerous over-the-road blind spots and expand your defensive field of vision with the rugged performance of the Truck-Lite 97618 5-Inch Round Convex Mirror Head. Specifically engineered as a compact, wide-angle auxiliary spot mirror, this premium convex glass assembly is designed to give long-haul truck drivers, delivery fleets, vocational operators, and heavy equipment technicians a clearer view of adjacent lanes, tight loading bays, and low-profile roadside traffic.
Say goodbye to fragile mirror housings that flake and scale over time. The 97618 features a heavy-duty, deep-drawn backing stamped entirely from corrosion-resistant high-tensile stainless steel with a natural high-polish silver finish. Engineered to take a beating from harsh road environments, highway de-icing treatments, and intense chassis vibrations, this structural steel shell keeps your glass secure. The high-clarity convex lens surface maximizes your panoramic sightline to capture what standard flat mirrors miss, keeping your equipment fully aligned with FMVSS 111 highway safety standards.
Installation is engineered to be quick, stress-free, and highly adjustable. The mirror head is equipped with a universal 5/16-inch (0.313 in.) adjustable female threaded ball stud system, a specialized design that shields the inner threads from stripping or external impact damage. For maximum mounting flexibility out of the box, this kit includes a zinc-plated universal structural steel "L" mounting bracket pack, allowing the assembly to be bolted onto west coast mirror loops, tripod fender bars, or utility truck body frames.
Directly replaces Signal-Stat 7313, 7314, and 7315; interchanges with Grote 28033, Peterson 654X, and Velvac 708520
